Printed glass can be laminated to one or more other glass panels for increased strength, safety or security. GTS can laminate the glass with clear, coloured or structural laminate to AS/NZS 2208 Printed glass can be laminated to one or more other glass panels for increased strength, safety or security. GTS can laminate the glass with clear, coloured or structural laminate to AS/NZS 2208 Grade A Safety Glass Standards.

This makes the product ideal for applications requiring stronger glass to meet stringent safety parameters, such as overhead glazing, awnings, ballustrades, railings, stairs, elevators and partitions.
Samples are sent to Kuraray for added quality assuranc. SGP Panels are regularly tested conformance to their product specifications. For testing results, see Our latest test results.

Our lamination process incorporates the same bagging system as Automotive Windscreens.
Toughened Laminate is much stronger than regular laminated glass for applications such as overhead glazing and swimming pool windows. EVA and SGP laminate film is also available.



EVA





EVA is an interlayer suitable for standard laminate and toughened laminate applications.
It has advantages over traditional PVB, due to its higher adhesion to glass and other substrates, non-absorption of water and better noise dampening.

Suited to outdoor balustrading and overhead glazing where the added strength of SGP is not required.
EVA is the predominant interlayer used in solar panels and plays an important role in preventing humidity and dirt penetrating the solar panels. EVA also helps to soften shocks and vibrations and therefore protecting the solar cells and its circuits.

SGP

SGP is an ionoplast interlayer that displays incredible strength and tear resistance.

SGP laminated glass has 5 times the tear resistance and 100 times the rigidity of standard laminates. It is especially suited to high strength engineered glass solutions that require increased security or strength or reduced weight.





    2019update 02

     image2019 13

logo   Leather material supplied by Shibori  and laminated for a unique splashback.



2019images 12 2019images 15

Enquire about our LAMLUX Materials for glass lamination range.

Perfect for creating a unique and durable design to enhance your space.

material update 23

A few samples of materials that can be used. Material catalog coming soon.
